200L Singal Pail Drum Tumbler
Specs for DT-S200 – 200 L Single-Drum Industrial Tumbler:
Explosion-Proof Tilt-to-Load Mixer for Closed-Drum Chemical and Adhesive Blending
Product Overview:
DrumTumbler Manufactures DT-S200 is a heavy-duty, explosion-proof single-drum tumbler designed for safe
mixing inside closed 200 L (≈ 55 gallon) drums.
Its corner-over-corner tumbling motion thoroughly re-blends settled or layered materials—ideal for
high-viscosity or flammable products that must remain sealed.
As a professional industrial drum mixer manufacturer, DrumTumble delivers efficient closed-drum
tumbling equipment trusted by global chemical and adhesive plants.
Technical Specifications:
| Specification | Details |
|---|---|
| Model | DT-S200 |
| Drum Capacity | One drum, 45 – 60 gallon (≈ 170 – 230 L) |
| Mixing Motion | Corner-over-corner tumbling |
| Motor Type | Explosion-proof, 3-phase motor |
| Voltage Options | 220 / 380 V, 50 – 60 Hz |
| Speed Range | Adjustable 0 – 18 RPM |
| Loading Method | Floor-level upright loading → tilt for mixing |
| Control System | Electric Control Box (required, sold separately) |
| Safety Enclosure | Guard Enclosure with Interlock (sold separately) |
| Structure | Heavy-duty carbon-steel frame with anti-vibration base |
| Compliance | Designed to meet OSHA / CSA / EU safety standards |
Key Features:
1)Powerful Corner-Over-Corner Action – Provides vigorous 3-D blending for complete homogenization.
2)Explosion-Proof Drive System – Safe for solvent-based or flammable chemicals.
3)Variable Speed (0 – 18RPM) – Match mixing intensity to material viscosity.
4)Closed-Drum Operation – No spills, vapors or contamination.
5)Floor-Level Loading – Easy handling with drum truck or hoist.
6)Tilt-to-Load Design – Compact, ergonomic layout saves space on production floors.
Safety & Handling:
1)Mix directly inside sealed drums to reduce operator exposure and spills.
2)Complies with OSHA / CSA / EU standards when used with interlocked enclosure.
3)Eliminates messy open-tank cleanups and cross-contamination risks.
Optional Accessories:
| Accessory | Description |
|---|---|
| Electric Control Box | Start/Stop and speed adjustment module (required). |
| Guard Enclosure with Interlock | OSHA/CSA/EU-compliant safety protection. |
| Drum Lifting Truck | For safe loading and unloading at floor level. |
| Explosion-Proof Wiring Kit | Suitable for hazardous-area installation. |
| Variable Speed Controller | Fine-tune rotation for different materials. |
Typical Applications:
1)Chip Bonding Adhesives – Re-mix stored electronic adhesives.
2)Catalysts & Curing Agents – Re-blend drums to restore uniform activity.
3)PU & Silicone Sealants – Re-homogenize before filling or dispensing.
4)UV & Screen Printing Inks – Maintain stable color and viscosity.
5)Paints & Coatings – Shake factory-sealed 55-gallon pails to restore finish.
6)Epoxy Resins – Ensure proper balance for two-component systems.
7)Solder Mask & Photoimage Inks – Prevent filler settling in precision coatings.
8)Battery Slurries & Conductive Pastes – Stabilize viscosity before coating.
9)Pigment Pastes & Color Concentrates – Re-disperse for masterbatch applications.
10)Pesticide Formulations – Re-mix suspensions for uniform active content.
11)Lubricants & Additives – Homogenize thick oil-based materials.
FAQ:
Q1: Can the DT-S200 mix flammable or solvent-based materials?
Yes. It is equipped with an explosion-proof motor and sealed drum design for hazardous applications.
Q2: What drum types are supported?
Standard 55-gallon (200 L) steel, plastic, or fiber drums.
Q3: Is a safety enclosure mandatory?
Yes. OSHA, CSA, and EU standards require use with an interlocked guard enclosure. However depends on your country safety requirements.
Q4: Is the speed adjustable?
Yes. Variable speed control from 0 to 20 RPM for different viscosities and batches.
Q5: Can this model be integrated with filling or dispensing systems?
Yes. The DT-S200 can connect with filling lines or pre-mixing stations for continuous production.
Packing method:
1)Inside with film packaging
2)Outside with wooden case
